Anthracite Bioclimatic Pergola 10x20 ft (3x6m) Motorized
Preorder
A deposit is required to confirm your order. The balance must be paid 2 weeks before the final delivery date. Estimated delivery time: 2 to 3 months.
Ref 15-721333
$6,999.00
Payment in 3 times without fees
3 x 2682.37 $
Description
The motorized bioclimatic pergola 10 x 20 ft (3 x 6 m) is available in two colors. Featuring a discreet electrical system, its motor is installed in one of the side beams. The various connections run inside the beams and exit through a post to be directly connected to your electrical system. An LED lighting kit is included and installs along the structure's gutters. This kit operates with the Tuya Smart app, available on the App Store and Google Play.
WARNING: The male electrical plug is not included.
Made of 99% aluminum and resistant to winds up to 62 mph (100 km/h), this pergola is designed for long-lasting durability. Thanks to its dual adjustable louvers, which can be tilted up to 135° and controlled via remote, you can customize sunlight, shade, and ventilation to your needs. Extensions on the beams allow the louvers to remain hidden from the outside when opened at 90°.
PRODUCT BENEFITS:
- Louvers adjustable up to 135° for optimal sun and shade control
- Waterproof IP67 motor
- High weather resistance with an integrated water drainage system in the posts
- Compatible with multiple accessories:
- Side screen 9.8 ft (3 m)
- Privacy panel 3.3 ft (1 m)
- Privacy panel 4.3 ft (1.3 m)
Technical Specifications
| Dimensions (L x W x H) |
19.6 x 9.6 x 8.4 ft (598 x 293 x 256 cm) Overall: 19.7 x 9.8 x 8.4 ft (600 x 300 x 256 cm) Clearance height: 8.1 ft (248 cm) |
| Weight | 569 lb (258.1 kg) |
| Material |
Structure and roof: Aluminum Fasteners and hardware: Steel (Dacromet), nylon, or plastic |
| Aluminum thickness | 1.4 - 1.8 mm |
| Colors |
Option 1: Anthracite gray - RAL 7015 Option 2: Anthracite gray and white - RAL 7015 and 9016 |
| Resistance |
Wind: 62 mph (100 km/h) Load: 10.2 lb/ft² (50 kg/m²) |
| Post dimensions | 4.6 x 4.6 in (11.6 x 11.6 cm) |
| Beam dimensions | 6 x 3 in (15.3 x 7.5 cm) |
| Dual louver dimensions | 112.4 x 6.7 x 1.2 in (285.5 x 16.9 x 3 cm) |
| Ground fixing plate dimensions | 6.3 x 6.3 in (16 x 16 cm) |
| Number of dual louvers | 38 |
| Warranty | 5 years |
| Additional Information |
Pergola ground fixing kit included: 4 concrete anchors per post, dimensions: M10 x 80 mm Screens and louvered panels sold separately. Images for reference only. The male electrical plug is not included. |
Our advice
The motorized bioclimatic pergola must be installed on a flat surface, ideally on a concrete slab.
If you are pouring concrete footings, we recommend a size of 10 x 10 in (25 x 25 cm).
If you are considering adding a screen or a louvered panel, we suggest purchasing and installing it at the same time as your pergola to ensure optimal anchoring to the ground.
If your pergola is already secured to the ground, make sure it is perfectly level (check with a level) and that the posts are positioned at 90° to facilitate the addition of accessories without any issues.
During winter, it is recommended to leave the louvers open in case of snowfall or strong winds to prevent any damage.
Depending on your municipality, installing this pergola may require a permit. We recommend checking with your local office for applicable regulations.
Package Information
Package Information
| Dimensions (W x D x H) | Weight | |
| Package 1 |
113 x 9.8 x 15.2 in (287 x 25 x 38.5 cm) |
150 lb (68.2 kg) |
| Package 2 |
117.3 x 17.3 x 8.5 in (298 x 44 x 21.5 cm) |
123 lb (55.7 kg) |
| Package 3 |
116 x 14.8 x 7.3 in (294.5 x 37.5 x 18.5 cm) |
121 lb (55 kg) |
| Package 4 |
116 x 13.6 x 7.3 in (294.5 x 34.5 x 18.5 cm) |
121 lb (55 kg) |
| Package 5 |
116 x 13.6 x 7.3 in (294.5 x 34.5 x 18.5 cm) |
112 lb (51 kg) |
