Available

Two-tone bioclimatic pergola 4x6M (13x20ft) motorized

Ref 15-721654

$8,399.00

Quantity

FREE DELIVERY

in southern Quebec.

Description

The Ombréa® 4x6M motorized bioclimatic pergola is available in 2 colors. Equipped with a discreet electrical system, its motor is installed in one of the pergola's side beams. The various connections run inside the beams and exit through a pergola post to connect directly to your electrical installation. An LED light kit is included with your pergola and attaches directly to the structure’s gutters. This kit operates via the Tuya Smart app, available for download on the App Store and Google Play.

WARNING: The male electrical plug is not included.

Made of 99% aluminum and designed to withstand winds up to 100 km/h (62 mi/h), this high-quality pergola allows you to adjust sunlight, shade, and ventilation thanks to its double adjustable louvers with a 135° rotation, controlled by a remote. Beam extensions are integrated so that when the louvers are opened at 90°, they are not visible from the outside.

KEY FEATURES:

Louvers adjustable up to 135° for optimal sun and shade management
Waterproof motor (IP67)
Highly weather-resistant with a built-in water drainage system inside the posts
Compatible with a wide range of accessories:
- Side shade 3 m (9.8 ft)
- Side shade 4 m (13.1 ft)
- Privacy panel 1 m (3.3 ft)
- Privacy panel 1.3 m (4.3 ft)

Technical Specifications

Dimensions (W x D x H)	600 x 400 x 256 cm (19.7 x 13.1 x 8.4 ft) Overall dimensions: 604 x 403 x 256 cm (19.8 x 13.2 x 8.4 ft) Height under pergola: 248 cm (8.1 ft)
Weight	341.8 kg (753 lb)
Material	Structure and roof: Aluminum Screws and hardware: Steel (Dacromet), nylon, or plastic
Aluminum thickness	1.4 - 1.8 mm
Colors	Color 1: Anthracite gray - RAL 7015 Color 2: Anthracite gray and white - RAL 7015 and 9016
Resistance	Wind: 100 km/h (62 mi/h) Load: 50 kg/m² (10.2 lb/ft²)
Post dimensions	13.6 x 13.6 cm (5.4 x 5.4 in)
Beam dimensions	19.5 x 9.5 cm (7.7 x 3.7 in)
Double louver dimensions	377 x 16.6 x 3.8 cm (148.4 x 6.5 x 1.5 in)
Ground fixing plate dimensions	16 x 16 cm (6.3 x 6.3 in)
Number of double louvers	38
Warranty	5 years
Information	Pergola ground fixing kit included. Four concrete screw anchors are provided per post, dimensions: M10 x 80 mm Shades and vented panels are sold separately. Images for reference only. The male electrical plug is not included.

To learn more

Why Choose a 6x4M Freestanding Bioclimatic Pergola?

Also known as a self-supporting pergola, a freestanding pergola has the advantage of being anchored to the ground with four posts. Unlike a wall-mounted model, which must be supported by a house wall, this structure is entirely independent. This means you can install it anywhere in your outdoor space, as long as the ground is stable.

Creating a true small oasis separate from your home, our freestanding pergola can serve as a second living space ideal for relaxation.

In addition to enhancing your property with its modern design, this exclusive Ombréa® model is highly versatile. You can set it up as an outdoor dining area, an outdoor kitchen, or even a cozy lounge by the pool.

With its dimensions of 6x4M, this freestanding pergola covers an area of approximately 24 m² (258 ft²). It provides enough space to accommodate a large family around a dining table or garden lounge set.

6x4M Bioclimatic Pergola: Features of the VS Collection

With our 6x4M freestanding bioclimatic pergola, you’ll enjoy a beautiful relaxation area all year round.

Thanks to its unique design, this structure will enhance your home’s patio or the outdoor space of your restaurant. It can be used as either an extension of your home or a separate island, depending on your preferences.

Advantages of Our Pergola

Complete waterproofing when the louvers are closed;
Posts equipped with an integrated drainage system;
Perfectly discreet louvers (invisible when opened to 90°);
Generous clearance height (2.4M / 7.9 ft);
Mounting kit included.

To top it off, this structure comes with a 5-year warranty. To create a relaxation area that complements your home, this collection is available in three colors: anthracite gray, white, or a mix of both.

Our Tips

The Ombréa® 4x6M bioclimatic pergola should be installed on a level surface, preferably a concrete slab.

If you are creating concrete footings, we recommend a size of 25 x 25 cm (9.8 x 9.8 in).

If you plan to purchase a screen or a louvered panel, we recommend buying and installing it at the same time as your pergola to ensure a secure fit.

If your pergola is already anchored to the ground, ensure it is perfectly level (check using a spirit level) and that the posts are positioned at 90° before adding any accessories.

It is recommended to keep the louvers open in winter in case of snowfall or strong winds.

As this pergola has a surface area greater than 20 m² (215 ft²), it may require a building permit.

Compatible accessories will be available soon for this model.

Our advice

Installation of the Ombréa 4x6M Freestanding Bioclimatic Pergola

The Ombréa 4x6M freestanding bioclimatic pergola should be installed on a flat surface, ideally on a concrete slab.

Ground Preparation

If you plan to pour concrete footings, we recommend a size of 25 x 25 cm (9.8 x 9.8 in).

Pergola Anchoring

The included hardware is designed for installation on solid walls. If installing on a hollow cinder block wall, use Molly anchors, nail-in anchors, or self-drilling anchors.

Adding Screens and Louvered Panels

If you plan to install a screen or a louvered panel, we recommend purchasing and assembling them at the same time as your pergola for optimal installation.

If your pergola is already anchored to the ground, ensure it is perfectly level using a spirit level and that the posts are positioned at 90° before adding accessories.

Winter Maintenance

In winter, we recommend keeping the louvers open in case of snowfall or strong winds to prevent damage to the structure.

Regulations

Installing this pergola may require a building permit. We recommend checking with your local municipality for necessary procedures.

Available Accessories

Up to 2 screens of 4M (13.1 ft)
Up to 2 screens of 6M (19.7 ft)

Package Information

	Dimensions (LxWxH)	Weight
Package 1 (posts and hardware)	8 feet 8 inches x 10.4 inches x 9.8 inches (approximately 265 x 26.5 x 25 cm)	89.3 lbs (approximately 40.5 kg)
Package 2 (upper frame and hardware)	10 feet 1.2 inches x 10.6 inches x 8.5 inches (approximately 308 x 27 x 21.5 cm)	81.6 lbs (approximately 37 kg)
Package 3 (slats and hardware)	9 feet 11.2 inches x 10.8 inches x 7.5 inches (approximately 302 x 27.5 x 19 cm)	97 lbs (approximately 44 kg)
Package 4 (slats)	9 feet 8.1 inches x 11.8 inches x 7.5 inches (approximately 295 x 30 x 19 cm)	103.6 lbs (approximately 47 kg)
